Frameset
Frame: 600 Series OCLV Carbon, KVF (Kammtail Virtual Foil) tube shape, Madone IsoSpeed, Micro-adjust seatmast, E2 tapered head tube, BB90, invisible cable routing, control centre, precision water bottle placement, Aero 3S chain keeper, DuoTrap S compatible
Fork: Madone KVF full carbon, carbon E2 tapered steerer, carbon dropouts, integrated brake and stem
Wheels
Wheels: Bontrager Aura Tubeless Ready
Tyres: Bontrager R3 Hard-Case Lite, 120tpi, aramid bead, 700x25c
Drivetrain
Shifters: Shimano Ultegra, 11-speed
Front derailleur: Shimano Ultegra, braze-on
Rear derailleur: Shimano Ultegra
Crank: Shimano Ultegra, 50/34 (compact)
Bottom bracket: BB90
Cassette:
Shimano Ultegra, 11-28, 11-speed
Components
Saddle: Bontrager Montrose Elite, titanium rails
Seatpost: Madone Micro-adjust carbon seatmast cap, 25mm offset
Handlebar: Madone Integrated Bar/Stem, KVF Profile, invisible cable routing, OCLV Carbon, VR-CF
Grips: Bontrager Supertack tape
Stem: Madone XXX Integrated bar/stem, OCLV Carbon, 7 degree, aero top cap pocket, w/computer and light mounts
Head set: Madone integrated, stainless cartridge bearings, sealed, 1-3/8" top, 1.5" bottom
Brake set: Madone aero, integrated
Weight
Weight:56cm - 7.58 kg / 16.71 lbs
