FRAME
Specialized M5 Premium Aluminum, Trail HT Geometry, integrated down tube battery, enclosed internal cable and Command Post IR routing, 148mm spacing
FORK
RockShox Recon Silver RL 29/27.5+, 15x110mm Maxle Lite thru-axle, Solo Air spring, adjustable rebound and lockout, 110/120mm of travel (size specific)
FRONT HUB
Specialized disc, alloy, sealed cartridge bearings, 110x15mm thru-axle, 24h
REAR HUB
Specialized disc, alloy, sealed cartridge bearings, 12x148mm thru-axle, 28h
SPOKES
Stainless, 14g, black
RIMS
Specialized 29, alloy disc, 23mm inner width, 24/28h
INNER TUBES
29x1.75/2.4", 40mm Presta valve
FRONT TYRE
Ground Control, Control casing, 29x2.3", 60TPI, Aramid folding bead, 2Bliss Ready
REAR TYRE
Fast Trak, Control casing, 29x2.2", 60TPI, Aramid folding bead, 2Bliss Ready
CRANKSET
Custom alloy crankarms
BOTTOM BRACKET
Integrated in motor
SHIFT LEVERS
Shimano Deore, RapidFire Plus, 10-speed
REAR DERAILLEUR
Shimano SLX, Shadow Plus, SGS cage, 10-speed
CASSETTE
Sunrace, 10-speed, 11-40t
CHAIN
SRAM PC1031, 11-speed w/PowerLink
FRONT BRAKE
Shimano Deore BL-M506, hydraulic disc, resin pad, 200mm rotor
REAR BRAKE
Shimano Deore BL-M506, hydraulic disc, resin pad, 180mm rotor
HANDLEBARS
Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 27mm rise, 750mm width
GRIPS
Specialized Body Geometry XCT Men's, lock-on
STEM
Specialized, 3D-forged alloy, 4-bolt, 6-degree rise, 31.8mm clamp
SADDLE
Body Geometry mountain, steel rails, 143mm
SEATPOST
Alloy, 2-bolt clamp, 12.5mm offset, 30.9mm, anti-corrosion hardware
SEAT BINDER
Alloy, 31.8mm
MOTOR
Custom & exclusive for Specialized, Trail tuned, 250 W
UI/REMOTE
Integrated Trail display, 10-LED battery display, Mission Control iOS/Android App
BATTERY
Custom LEVO battery, 460Wh, 40x3.2Ah, ANT+/Bluetooth connectivity, IP 67
CHARGER
Custom charger, 42V4A w/Rosenberger plug
WIRING HARNESS
Custom harness w/ Rosenberger plug
