FRAME
Specialized M5 Premium Aluminum, Trail Geometry, integrated down tube battery, enclosed internal cable and Command Post IR routing, 148mm spacing, fully sealed cartridge bearings, 140mm of travel
FORK
RockShox Pike RC 29/27.5+, Solo Air, compression and rebound adjust, tapered steerer, 15x110mm Maxle Stealth thru-axle, 51mm offset, 140mm travel
REAR SHOCK
FOX FLOAT Factory, Rx Trail Tune, AUTOSAG, DPS damper, Kashima coating, rebound and 3-position compression and Open adjust, 197x47.6mm
FRONT HUB
Roval Traverse, sealed cartridge bearings, 15mm thru-axle, 110mm spacing, 24h
REAR HUB
Roval Traverse, DT Swiss internals, sealed cartridge bearings, SRAM XD driver body, 12mm thru-axle, 148mm spacing, 28h
SPOKES
DT Swiss Revolution
RIMS
Roval Traverse 650b, hookless alloy, 38mm inner width, 24/28h, tubeless ready
INNER TUBES
650bx2.3"/3.0", 40mm Presta valve
FRONT TYRE
Purgatory, GRID casing, 650bx3.0", 60TPI, Aramid folding bead, 2Bliss Ready
REAR TYRE
Purgatory, GRID casing, 650bx3.0", 60TPI, Aramid folding bead, 2Bliss Ready
CRANKSET
Custom alloy crankarms
SHIFT LEVERS
SRAM X1, 11-speed, trigger
REAR DERAILLEUR
SRAM X01, carbon cage, 11-speed
CASSETTE
SRAM XG-1180, 11-speed, 10-42t
CHAIN
SRAM PCX1, 11-speed w/PowerLink
FRONT BRAKE
SRAM Guide RS carbon, hydraulic disc, organic pads, carbon lever, Guide S4 4-piston caliper, 200mm rotor
REAR BRAKE
SRAM Guide RS, hydraulic disc, organic pads, Guide S4 4-piston caliper, 200mm rotor
HANDLEBARS
Specialized Trail, 7050 alloy, 8-degree backsweep, 6-degree upsweep, 25mm rise, 750mm width, 31.8mm
GRIPS
Specialized Sip Grip, light lock-on, half-waffle, S/M: regular thickness, L/XL: XL thickness
STEM
Specialized Trail, 3D forged alloy, 4-bolt, 6-degree rise
SADDLE
Body Geometry Henge Comp, hollow Cr-Mo rails, 143mm
SEATPOST
Command Post IRcc, 12 position micro-height adjustable, alien head design, bottom mount cable routing, remote SRL lever, 30.9mm, S: 100mm, M/L/XL: 125mm travel
SEAT BINDER
Alloy, 34.9mm
MOTOR
Custom & exclusive for Specialized, Trail tuned, 250 W
UI/REMOTE
Integrated Trail display, 10-LED battery display, Mission Control iOS/Android App
BATTERY
Custom Levo Battery, 504Wh, 40x3.5Ah, ANT+/Bluetooth® connectivity, IP 67
CHARGER
Custom charger, 42V4A w/Rosenberger plug
WIRING HARNESS
Custom harness w/ Rosenberger plug
