Frame | 600 Series OCLV Carbon, front & rear IsoSpeed, tapered head tube, Control Freak internal routing, Ride Tuned seatmast, 3S chain keeper, flat-mount disc, 142x12 mm thru axle |
---|
Fork | Trek IsoSpeed Cross full carbon, tapered carbon steerer, flat-mount disc, 395 mm axle-to-crown, 12x100 mm thru axle |
---|
Front wheel | Bontrager Paradigm Comp 25, Tubeless Ready, 25 mm rim width, 100x12 mm thru axle |
---|
Rear wheel | Bontrager Paradigm Comp 25, Tubeless Ready, 25 mm rim width, Shimano 11-speed freehub, 142x12 thru axle |
---|
Tyre | Bontrager CX3 Team Issue, aramid bead, 120 tpi, 700x32 c |
---|
Shifter | Shimano GRX RX810, 11 speed |
---|
Rear derailleur | Shimano GRX RX810, long cage, 34T max cog |
---|
*Crank | Size: 47, 50, 52 Shimano GRX RX810, 40T ring, 170 mm length |
---|
Size: 54, 56 Shimano GRX RX810, 40T ring, 172.5 mm length |
Size: 58, 61 Shimano GRX RX810, 40T ring, 175 mm length |
Bottom bracket | Trek BB90 |
---|
Cassette | Shimano Ultegra HG800-11, 11-34, 11-speed |
---|
Chain | Shimano Ultegra HG701, 11-speed |
---|
*Saddle | Size: 47, 50, 52 Bontrager P3 Verse Comp, steel rails, 155 mm width |
---|
Size: 54, 56, 58, 61 Bontrager P3 Verse Comp, steel rails, 145 mm width |
*Seatpost | Size: 47, 50, 52, 54, 56 Bontrager carbon seat mast cap, 20 mm offset, short length |
---|
Size: 58, 61 Bontrager carbon seat mast cap, 20 mm offset, tall length |
*Handlebar | Size: 47 Bontrager Elite IsoZone VR-CF, alloy, 31.8 mm, 93 mm reach, 123 mm drop, 38 cm width |
---|
Size: 50, 52 Bontrager Elite IsoZone VR-CF, alloy, 31.8 mm, 93 mm reach, 123 mm drop, 40 cm width |
Size: 54, 56 Bontrager Elite IsoZone VR-CF, alloy, 31.8 mm, 93 mm reach, 123 mm drop, 42 cm width |
Size: 58, 61 Bontrager Elite IsoZone VR-CF, alloy, 31.8 mm, 93 mm reach, 123 mm drop, 44 cm width |
Handlebar tape | Bontrager Supertack Perf tape |
---|
*Stem | Size: 47 Bontrager Pro, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length |
---|
Size: 50 Bontrager Pro, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length |
Size: 52, 54 Bontrager Pro, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length |
Size: 56, 58 Bontrager Pro, 31.8 mm, Blendr-compatible, 7-degree, 100 mm length |
Size: 61 Bontrager Pro, 31.8 mm, Blendr-compatible, 7-degree, 110 mm length |
Brake | Shimano RX400 hydraulic disc |
---|
Brake rotor | Shimano RT800, 160 mm, CenterLock |
---|
Weight | 56 - 8.23 kg / 18.14 lbs |
---|
Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb). |
---|
