SPECIFICATION
COLOUR Matt Zinc Grey/Lime
CASSETTE SRAM PG-1230 Eagle, 11-50, 12 Speed
FRAME Carbon, Uni-directional Multi Monocoque Front Triangle with Internal Cable Routing, Tapered Head Tube, Intergrip Seat Clamp System, Alloy Symmetrical SCR Rear Triangle and 148mm Boost Dropouts
CHAIN SRAM Eagle, 12 Speed
FORK Fox Float Performance SC 34, Step Cast, 29", 120mm Travel, 44mm Offset, GRIP 3-Pos Damper, Tapered Steerer, Black Coating, 110mm x 15mm Boost, E-Thru Axle
CRANKSET SRAM Stylo 6K Eagle, X-SYNC 2, Direct Mount 34T, Boost, 175mm, 12 Speed
REAR SHOCK Fox Float DPS, Performance, Black Coating, Rebound Adjustment and 3pos Adjust Evol LV
BOTTOM BRACKET SRAM DUB, BSA, 73mm
HEADSET FSA No. 42 Orbit ZS Plus, Integrated, 1 1/2" Lower and 1 1/8" Upper Sealed Cartridge Bearings
SEATPOST KS RAGEi, Dropper Post, 30.9mm, S 125mm Travel, M/L/XL 150mm Travel, Southpaw-Alloy Remote Lever
REAR HUB Alloy, Double Sealed Cartridge Bearings, 12mm x 148mm Boost Through Axle, 32 Hole
SADDLE Whyte Custom Dual Density, Triple Panel Design
FRONT HUB Alloy, Double Sealed Cartridge Bearings, 15mm x 110mm Boost Through Axle, 32 Hole
HANDLEBAR Whyte 6061 Alloy, 15mm Low Rise, 31.8mm, 780mm Wide
SPOKES DT Swiss Champion 2.0mm, Black Stainless, Brass Nipples
STEM Whyte Gravity Stem, 40mm Extension
RIMS WTB ST i27 TCS 2.0 System, Pinned Joint, Tubeless Ready, 32 Hole
GRIPS Whyte Lock-on V Grip
TYRE Maxxis Forekaster TR 29" x 2.35" 120TPI 3C MaxxSpeed Compound, EXO Sidewall Protection, Front, Ardent Race TR 29" x 2.35" 60TPI Dual Compound, EXO Sidewall Protection, Rear
BRAKES FRONT SRAM Guide T, 4 Pot, 180mm Rotor
SHIFT LEVERS SRAM NX Eagle, Matchmaker, 12 Speed
BRAKES REAR SRAM Guide T, 4 Pot, 180mm Rotor, Internal Routing
FRONT MECH N/A
BRAKE LEVERS SRAM Guide T, Matchmaker
REAR MECH SRAM NX Eagle, 12 Speed PEDALS None
WEIGHT 14
