Weight
14.50 kg / 31.97 lb (with tubes)
Frame
Alpha Silver Aluminium, internal routing, chainstay disc-brake mount, rack and kickstand mount, 135x5 mm QR
Fork
SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 51mm offset for 29" wheel, 100 mm QR, 100 mm travel
Front Suspension
SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 51mm offset for 29" wheel, 100 mm QR, 100 mm travel
Front Hub
Formula DC-20, alloy, 6-bolt, 5x100 mm QR
Rear Hub
Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR
Rims
Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve
Tyres
Bontrager XR2 Comp, wire bead, 30 tpi, 29x2.20"
Shifters
Shimano Altus M315, 8-speed
Front Derailleur
Shimano Altus M315, 34.9 mm clamp, top swing, dual pull
Rear Derailleur
Shimano Altus M310
Crank
Shimano M315, 36/22
Bottom Bracket
VP BC73, 73 mm, threaded cartridge
Cassette
Shimano HG31, 11-34, 8-speed
Chain
KMC Z8.3, 8-speed
Pedals
VP-536 nylon platform
Saddle
Bontrager Arvada, steel rails
Seatpost
Bontrager alloy, 31.6 mm, 12 mm offset
Handlebar
Bontrager alloy, 31.8mm, 5mm rise
Stem
Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree
Grips
Bontrager XR Endurance Comp
Headset
Semi-integrated, 1-1/8"
Brakeset
Tektro HD-M276 hydraulic disc, short-reach lever
