SPECS Specifications subject to change without notice.
FRAME FACT 11m carbon chassis and rear-end, asymmetrical design, 29
Trail Geometry, SWAT™ Door integration, head tube angle
adjustment, horst pivot BB adjustment, threaded BB, fully
enclosed internal cable routing, 12x148mm dropouts, sealed
cartridge bearing pivots, replaceable derailleur hanger, 150mm of
travel
SWAT Increased-volume SWAT™ Door integration with 22oz SWAT™
Bladder
REAR SHOCK FOX FLOAT X Performance, Rx Trail Tune, EVOL Air sleeve,
2-position lever w/ LSR adjustment, S1:210x50mm,
S2-S6:210x55mm
FORK FOX FLOAT 36 Rhythm, GRIP damper, two position Sweep
adjustment, 15x110mm QR axle, 44mm offset, S1: 150mm of
travel, S2-S6: 160mm of travel
STEM Alloy Trail Stem, 35mm bar bore
TAPE Specialized Trail Grips
SADDLE Bridge Comp, Hollow Cr-mo rails, 155/143mm
HANDLEBARS Specialized, 6061 alloy, 6-degree upsweep, 8-degree
backsweep, 30mm rise, 780mm width
FRONT BRAKE SRAM Code RS, 4-piston caliper, hydraulic disc, 200mm
Centerline
REAR BRAKE SRAM Code RS, 4-piston caliper, hydraulic disc, 200mm
Centerline
REAR DERAILLEUR SRAM GX Eagle, 12-speed
SHIFT LEVERS SRAM GX, trigger, 12-speed
CASSETTE Sram XG-1275, 12-speed, 10-52t
CHAIN SRAM NX Eagle, 12-speed
CRANKSET SRAM X1 Eagle, DUB, 32T, S1: 165mm, S2-S5: 170mm, S6:
175mm
CHAINRINGS 32T
BOTTOM BRACKET SRAM DUB, BSA 73mm, Threaded
FRONT HUB Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h
RIMS Specialized 29, hookless alloy, 30mm inner width, tubeless ready
REAR HUB Alloy, sealed cartridge bearings, 148mmx12mm thru-axle, 28h
FRONT TIRE Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss
Ready, 29x2.3"
SPOKES DT Swiss Industry
REAR TIRE Eliminator, GRID TRAIL casing, GRIPTON® T7 compound,
29x2.3"
INNER TUBES Standard, Presta Valve
SEATPOST X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount
cable routing, remote SLR LE lever, 34.9, S1: 100mm, S2:
125mm, S3: 150mm, S4/S5: 175mm, S6: 190mm
SEAT BINDER Alloy, 38.6mm
