Colour
Matt Diesel with Light Blue & Slate
Sizes Available
XS,S,M,L,XL
Frame
6061 Alloy, Hydro Formed T6 Aluminium, Multi Butted, Custom Drawn, Tapered Headtube, Internal Cable Routing, Shape.it Link and 12mm X 148mm Boost Dropouts
Fork
RockShox ZEB 27.5”, 160mm Travel, 44mm Offset, DebonAir, Charger R Damper, Fast Black Coating, Tapered Steerer, 110mm x 15mm Boost, Maxle Ultimate
Rear Shock
RockShox Deluxe Select + RT, DebonAir, Fast Black Coating, Adjustable Rebound, 2 position compression adjustment
Headset
FSA No. 57E Orbit ZS, 1 1/2” Lower and 1 1/8” Upper Sealed Cartridge Bearings
Rear Hub
Alloy, e-bike specific, Double Sealed Cartridge Bearings, 12mm x 148mm Boost Thru Axle, 32 Hole
Front Hub
Alloy, Double Sealed Cartridge Bearings, 15mm x 110mm Boost Thru Axle, 31mm Torque Caps, 32 Hole
Spokes
DT Swiss Champion 2.0mm, Black Stainless, Brass Nipples
Rims
WTB HTZ i30 TCS 2.0 System, Asymmetric, Sleeved Joint, Super Tough Construction, Tubeless Ready, 32 Hole
Tyres
Maxxis Assigai WT, TR, 27.5” x 2.5” 120TPI, EXO+ Casing, 3C Maxx Terra, Dual Compound, Front, Maxxis Minion DHR WT, TR, 27.5” x 2.4” 120TPI, Double Down, 3C Maxx Terra, Dual Compound, Folding Bead, Rear
Shift Levers
SRAM GX-E, Eagle, Single Click, MMX, 12 Speed
Front Derailleur
N/A
Rear Derailleur
SRAM GX Eagle, 12 Speed
Cassette
SRAM PG-1210 Eagle, 11-50, 12 Speed
Chain
SRAM GX Eagle, 12 Speed
Crankset
SRAM EX1, 165mm, ISIS with X-SYNC 2, Direct Mount 36T for Bosch Performance Line CX, Black
Bottom Bracket
N/A
Seatpost
Whyte drop.it Adjust, 30.9mm, XS/S 120-150mm Travel, M/L 140-170mm Travel, XL 170-200mm Travel, MMX Paddle Remote Lever
Seat
Fizik Terra Aidon, 145mm wide, Wingflex, S-Alloy Mobius rail
Bar
Whyte Custom 6061 Alloy, 30mm Rise, 35mm Bar Bore, 780mm Wide
Stem
Whyte Enduro Stem, 35mm Bar Bore, 35mm Extension
Grips
Whyte Lock-on Enduro Grip
Front Brakes
SRAM Guide RE, 4 Piston with Sintered Metal Pads, 220mm Disc
Rear Brakes
SRAM Guide RE, 4 Piston with Sintered Metal Pads, 200mm Disc
Brake Levers
SRAM Guide RE, MMX
Pedals
None
