Colour
Matt Moss with Chalk & Ocean
Sizes Available
S,M,L,XL
Frame
6061 Alloy, Hydro Formed T6 Aluminium, Multi Butted, Custom Drawn, Tapered Headtube, Internal Cable Routing, Shape.it Link and 12mm X 148mm Boost Dropouts
Fork
Fox Float 38, Performance 27.5”, 160mm Travel, 44mm Offset with Grip Damper, 3pos Adjust and custom tune, Tapered Steerer, 110mm x 15mm Boost, E-Thru Axle
Rear Shock
Fox Float Performance DPS, Evol LV, 3pos adjustable Compression and Rebound damping
Headset
FSA No. 57E Orbit ZS, 1 1/2” Lower and 1 1/8” Upper Sealed Cartridge Bearings
Rear Hub
Alloy, e-bike specific, Double Sealed Cartridge Bearings, 12mm x 148mm Boost Thru Axle, 32 Hole
Front Hub
Alloy, Double Sealed Cartridge Bearings, 15mm x 110mm Boost Thru Axle, 32 Hole
Spokes
DT Swiss Champion 2.0mm, Black Stainless, Brass Nipples
Rims
WTB HTZ i30 TCS 2.0 System, Asymmetric, Sleeved Joint, Super Tough Construction, Tubeless Ready, 32 Hole
Tyres
Maxxis Assigai WT, TR, 27.5” x 2.5” 120TPI, EXO+ Casing, 3C Maxx Terra, Dual Compound, Front, Maxxis Minion DHR WT, TR, 27.5” x 2.4” 120TPI, Double Down, 3C Maxx Terra, Dual Compound, Folding Bead, Rear
Shift Levers
SRAM GX-E, Eagle, Single Click, MMX, 12 Speed
Front Derailleur
N/A
Rear Derailleur
SRAM X01 Eagle, 12 Speed
Cassette
SRAM XG-1275 Eagle, 10-52, 12 Speed
Chain
SRAM GX Eagle, 12 Speed
Crankset
SRAM EX1, 165mm, ISIS with X-SYNC 2, Direct Mount 36T for Bosch Performance Line CX, Black
Bottom Bracket
N/A
Seatpost
Crank Bro High-Line 3, 30.9mm, XS/S 125mm Travel, M/L 150mm XL 170mm Travel, High-Line Ball Socket Remote Lever
Seat
Fizik Terra Aidon, 145mm wide, Wingflex, S-Alloy Mobius rail
Bar
Whyte Custom 6061 Alloy, 30mm Rise, 35mm Bar Bore, 780mm Wide
Stem
Whyte Enduro Stem, 35mm Bar Bore, 35mm Extension
Grips
Whyte Lock-on Enduro Grip
Front Brakes
SRAM Code R, 4 Piston with Sintered Metal Pads, 220mm Disc
Rear Brakes
SRAM Code R, 4 Piston with Sintered Metal Pads, 200mm Disc
Brake Levers
SRAM Code R, MMX
Pedals
None
