Fork
Suntour Mobie 34 DS RLR, air, ABS, 100 mm, 15x110 mm axle
Fork-Suspension-Travel
100
Derailleur
Shimano Cues, RD-U8000, Shadow Plus
Shift-Levers
Shimano Cues, SL-U8000, 1x11-speed, rapidfire plus-shifter
Number-Of-Gears
11
Brake-Front
Magura MT-C, hydraulic disc brake, 4-piston, ABS
Brake-Rear
Magura MT-C, hydraulic disc brake
Brake-Lever-Front
Magura MT-C, hydraulic disc brake
Brake-Lever-Rear
Magura MT-C, hydraulic disc brake
Brake-Disc-Front
Magura MDR-C CL, 203 mm
Brake-Disc-Rear
Magura MDR-C CL, 203 mm
Rims
Cross X18, disc, eyelets, width: 30 mm
Tire-Front
Schwalbe Marathon Mondial, Performance, RaceGuard, reflective stripe, 57-622
Tire-Rear
Schwalbe Marathon Mondial, Performance, RaceGuard, reflective stripe, 57-622
Hub-Front
Shimano HB-TC500-B, centerlock, disc, 15x110 mm axle
Hub-Rear
Shimano FH-QC400, centerlock, disc, quick release
Spokes
Stainless, black
Handlebar
Syncros 3.0, riserbar, backsweep: 15°, rise: 12 mm
Handlebar-Width
680
Handlebar-Rise
15
Handlebar-Backsweep
15
Stem
Satori Python, adjustable
Stem-Length
90
Headset
Acros, A-Headset, semi-integrated, tapered, with integrated cable routing
Grips
Syncros Urban, Ergo, double density, lock-on
Saddle
Syncros Capilano Trekking
Seat-Post
Syncros Duncan, dropper post
Seat-Post-Dropper-Travel
120
Crankset
FSA CK-745, 170 mm, 38t
Bottom-Bracket
Bosch, Isis
Drive
Shimano Linkglide, CN-LG500
Sprocket
Shimano Cues, CS-LG700-11, 11-50t
Pedals
Trekking alloy, platform
Front-Light
Trelock LS890-HB LED, 100/130 Lux high beam
Rear-Light
Axa Juno, LED, with brake light function
Rack
Racktime / BGM Trekking Pro, Snapit 2.0 System
Mudguards
Curana Orbit, with stainless stays
Chainguard
Integrated in motor cover
Stand
Syncros U-mount
Motor
Bosch Smart System, Performance Line CX (BDU384Y), 250 W, 36 V, max. 25 km/h
Battery
Bosch PowerTube, 36 V Li Ion, 800 Wh
Battery-Capacity
800
Number-Of-Batteries
1
Display
Bosch Kiox 300 with LED Remote
Charger
Bosch Standard Charger, 4A
